RUSTA ADVANCED Gebrauchsanweisung Seite 78

Step 16
Connect Arched Tube (# 28) to the two sides of Short Horizontal Tubes using Arc Washer (# G), Spring Lock
Washer (# E), Screw (# F) and Allen Wrench (# I) as shown in FIGURE 26.
Repeat the same for all Arched Tubes.
ENG
SE NO
15
Step 17
Slide Curved Vertical Tube (# 23) into the bottom sleeves of Enclosure Netting (# 29) as shown in FIGURE 27.
Repeat the same for all Curved Vertical Tubes.
16
# 23
Step 18
Connect Curved Vertical Tube (# 23) to Arched Tube (# 28) using Arc Washer (# G), Spring Lock Washer (# E),
Screw (# F) and Allen Wrench (# I) as shown in FIGURE 28. Repeat the same for all four tubes.
78
IM_759013120301_Trampoline_Advanced_550x400cm_v3.indd 78
DISASSEMBLY OF THE TRAMPOLINE AND ENCLOSURE
DE FI
DISASSEMBLY OF THE TRAMPOLINE AND ENCLOSURE
# 23
# I
# F
# E
# 28
32
# G # E # F # I
FIGURE 26
# 23
# 23
FIGURE 27
# 28
