RUSTA ADVANCED Gebrauchsanweisung Seite 62

FIGURE 11.
Step 6 –Attach Side Leg Supports
ENG
SE NO
Attach the Side Leg Supports assembled in Step 5 to form the trampoline frame as shown below. Secure all
tubes using Arc Washer (# G), Spring Lock Washer (# E), Screw (# F) and Allen Wrench (# I) as shown in
FIGURE 11.
6
# 13
# 13
Hint: Make sure the holes on all the steel tubing parts are aligned and are facing outward.
Hint: Make sure the holes on all the steel tubing parts are aligned and are facing outward.
The complete trampoline frame should look as shown in FIGURE 12.
The complete trampoline frame should look as shown in FIGURE 12.
62
IM_759013120301_Trampoline_Advanced_550x400cm_v3.indd 62
DE FI
# 15
# 13
# 15
TRAMPOLINE FRAME ASSEMBLY
# 13
20
20
# G
# G # E # F# I
FIGURE 1
FIGURE 11
FIGURE 12
FIGURE
