CARDIOSTRONG EX80 Plus Touch Montage- Und Bedienungsanleitung Seite 43

Nr. Bezeichnung (ENG)
B31 Bush
B32 Bearing 6003Zz
B33 Bush
B34 Screw
B35 Pedal Reinforcement Strip
B36 Screw
C1 Side Connecting Tube ( L )
C2 Side Connecting Tube ( R )
C3 Adjusted Nut
C4 Adjusted End
D Console Supporting Tube
D1 Sensor Wire
D2 Handl Pulse Ring
D3 Handl Pulse Wire
D4 Spacer Ring
D5 Handle Pulse
D6 Upper Handle Pulse Housing
D7 Loewr Handle Pulse Housing
D8 Handle Pulse Ring
D9 Foam Spacer Ring
D10 Spong Hdr
D11 Spong Hdr
Anz. Nr. Bezeichnung (ENG)
2 D12 Screw M3 X 8
4 D13 End Cap
2 E1 Handle Bar ( L )
4 E2 Handle Bar ( R )
4 F1 Central Supporting Tube
8 F2 Iron Bracket
1 F3 Central Supporting Tube Cover ( L )
1 F4 Central Supporting Tube Cover ( R )
2 F5 Screw
2 F6 Screw
1 G Console
1 G1 Screw
2 H Water Bottle Holder
2 J1 Screw M8 X 16
2 J2 Screw M8 X 60
4 J3 Bolt M12 X 73
2 J4 Nut M12
2 J5 Bolt M12 X 109
2 J6 Screw M5
2 J8 Screw M8 X 20
2 J9 Washer M12
2 I Adaptor
Anz.
4
2
1
1
1
1
1
1
4
2
1
4
1
4
4
2
4
2
2
2
4
1
43
