Teileliste - CARDIOSTRONG FX80 Montage- Und Bedienungsanleitung

8.2

Teileliste

Nr. Bezeichnung (ENG)
1 Main frame
2 Upright post
3 Sliding rail
4 Crank
5 Left lower handlebar
6 Right Lower handlebar
7 Pulse circular tube
8 body arm Left
9 body arm Right
10 Swing arm right
11 Swing arm Left
12 Sliding rail Aluminum plate
13 Cover decoration
14 Left upper handlebar
15 Right upper handlebar
16 Bearing base
17 Circlip for shaft Φ20
18 Upright post connection plate (1)
19 Console frame group
20 Bearing base
21 Magnet fix
22 Magnet control fixed axis Φ12×50
23 Hex full thread screw M5*60
24 Allen C.K.S full thread screw M10*60
25 Hex full thread screw M6*15
26 Hex half thread screw M10*75*20
27 Allen C.K.S. hollow screw Φ8*33*M6*15
28 Allen C.K.S. full thread screw M6*15
29 Allen cylinder head full thread screw M6*10
30 Allen cylinder head full thread screw M8*15
31 Allen cylinder head full thread screw M8*20
40
Anz.
1
1
1
2
1
1
1
1
1
1
1
4
1
1
1
2
1
1
1
1
1
1
1
1
2
2
2
18
8
13
4
FX80
