Tool Specifications

Type
Nom. power requirement [W]
-1
Rated rpm [min ]
1st speed
2nd speed
-1
Rated rpm (no load) [min ]
1st speed
2nd speed
-1
Pulse frequency [min ]
1st speed
2nd speed
Speed selection
Reverse rotation
Ring gear chuck
Keyless chuck
with automatic lock
Mains cable module (Plug-it)
Drill chuck capacity range
Drill chuck thread
Bit holder, hexagonal socket
Drill dia. [mm] steel
aluminium
wood
concrete
Clamping collar dia. [mm]
Weight
Protection class

Operating controls

1 Key-type drill chuck
2 Spanner surface
3 Auxiliary handle collar
4 Drill/Percussion drill switch (PDP 20-2 EQ/EAQ)
5 Ventilation slots
6 Lock-on button
7 Mains cable module
8 ON/OFF switch
9 Speed selector thumbwheel
10 Rotational direction switch
11 Gear selector switch
12 Auxiliary handle
13 Depth stop
14 Socket
15 Sleeve
16 Securing screw
17 Chuck key
18 Open-ended spanner
19 Allen key
20 Keyless chuck (DRP 8 E/13 E-1)
21 Screwdriver attachment
22 Safety cover
23 Drill spindle
Not all of the accessories illustrated or described are
included as standard delivery.
Drill
DRP 13-2EQ DRP 13-2EAQ
630 630
0 ... 500 0 ... 500
0 ... 1450 0 ... 1450
0 ... 1000 0 ... 1000
0 ... 2900 0 ... 2900
– –
– –
• •
• •
• –
• •
– •
• •
1.5 ... 13 1.5 ... 13
1/2" - 20 UNF 1/2" - 20 UNF
1/4" 1/4"
13 13
16 16
35 35
– –
43 43
2.0 kg 2.1 kg
II / II /

Notes on Safety

Impact Drill
PDP 20-2EQ
760
0 ... 600
0 ... 1750
0 ... 1100
0 ... 3050
0 ... 22 000
0 ... 61 000
•
•
•
•
–
•
1.5 ... 13
1/2" - 20 UNF
1/4"
13
25
45
20
43
2.1 kg
II /
This machine can only be operated safely
when the operating instructions and the
pamphlet containing the safety instruc-
tions have been completely read and
strictly adhered to.
For further notes on safety refer to enclosed Sheet.
Always inspect cable and plug before using machine.
Only have damage repaired by a qualified professional.
Make sure machine is switched off before inserting
plug in socket.
The machine must not be damp and must not be oper-
ated in a wet environment.
Caution with long hair. Do not wear loose-fitting cloth-
ing while working.
Secure your workpiece with clamps.
Always direct power cable to rear away from the
machine.
When screwdriving, always operate in first gear and
with low rpms.
Use caution when screwdriving long screws. Danger of
injury due to slipping off.
Always ensure that you have a secure footing while
working.
Always use the auxiliary handle (12) if possible.
Watch out for the initial torque reaction of the drill,
especially when drill bit is tight.
GB
PDP 20-2EAQ
760
0 ... 600
0 ... 1750
0 ... 1100
0 ... 3050
0 ... 22 000
0 ... 61 000
•
•
–
•
•
•
1.5 ... 13
1/2" - 20 UNF
1/4"
13
25
45
20
43
2.2 kg
II /
