Malpositioning of the intervertebral
disk prosthesis due to failure to
observe the midline!
Check the central position of
WARNING
the trial implant by means of
the midline marking and on the
AP-view X-ray image.
Ensure that the position of the
trial implant does not change
during reaming.
Risk of injury to nerves and spinal
cord caused by too deep insertion
of the reamer!
Only use activC instruments.
WARNING
Use the instruments according
to their intended use.
For reaming the holes, apply the
reamer only in combination with
a correctly
positioned trial implant and
with the reamer guide coupled.
Ensure that the depth stop of
the trial implant abuts to the
anterior edge of the vertebral
body.
Always maintain lateral X-ray
control while reaming the holes.
To ream the first hole under lateral X-ray control:
With the motor running, push reamer handpiece 6
at an even speed and with slight forward pressure
into the first guiding slot down to the stop.
Pull back reamer handpiece 6 and, after moving
the pins of mounting block 4 to the second guiding
slot, repeat the reaming procedure under lateral X-
ray control.
The reaming depth will be limited by the stop at
reamer guide 3.
With the hand control inactivated, shift the safety
stop on the pneumatic motor to position "0".
Cautiously pull out reamer handpiece 6 first from
the rear and then from the frontal reamer guide 3.
Remove the reamer guide 3 and trial implant from
the intervertebral disk space. Clean the fin bed with
nerve hooks from the discectomy set.
Chiseling the fin bed/Mounting the reamer
guide
Note
The handle and the chisel guide are fitted with identical
locking mechanisms.
Turn the locking pipes 11 of the chisel guide 10 to
the "open" position
Mount the chisel guide 10 onto the trial implant in
the intervertebral space. Note the "CRANIAL" and
"CAUDAL" markings on the handle and on the trial
implant.
selected and Turn locking pipes 11 of chisel guide 10 to position
"closed"
Chisel guide 10 is fixed to the trial implant.
Check again, by X-ray imaging, the position of the
trial implant.
WARNING
Mount chisel onto the chisel holder as shown.
To do this, attach the chisel on the side of the
chisel holder 9 and push back until it engages.
Pull to check if the chisel is engaged properly.
.
.
Damage to nerves, spinal cord and
other tissue because of fin bed
reamed too deeply due to using too
long a chisel.
Only use chisel holder FW786R.
Only use chisel FW787R.
