Aesculap Spine
activ C handle, reamer guide, chisel guide, trial implants
Infection hazard for patients
and/or users and impairment
of product functionality due
to reuse. Risk of injury, illness
DANGER
or
contamination
impaired functionality of the
product!
Do
product.
Note
The reaming of the fin bed determines the position and
orientation of the disk prosthesis in the plane of the
intervertebral disk. The fin bed must only be prepared
for the inferior implant plate.
Malpositioning of the intervertebral
disk prosthesis due to failure to
observe the midline!
Check the central position of
WARNING
the trial implant by means of
the midline marking and on the
AP-view X-ray image.
Ensure that the position of the
trial implant does not change
during reaming.
6
death due to
and/or
not reprocess the
Risk of injury from sharp reamer!
To avoid injuries to critical
blood vessels, nerves and other
tissue, as well as injuries to the
WARNING
operating surgeon, always work
with appropriate care when a
reamer
machine.
Do not activate the motor
before the handpiece with the
coupled
positioned in the guide hole and
the guiding slot of the reamer
guide.
A: Position reamer handpiece 6 with the coupled
reamer through the frontal guide hole of reamer
guide 3, see Fig. 5.
B: Position the laterally protruding pins of
mounting block 4 through the rear guiding slots of
reamer guide 3, see Fig. 5.
A
Fig. 5 Sliding the reamer handpiece into the reamer
guide
With the hand control inactivated, push the safety
stop to .
The system is ready for operation.
Note
The reaming of the fin bed determines the position and
orientation of the disk prosthesis in the plane of the
intervertebral disk.
is clamped in the
reamer is properly
B
