Navkom Bioreader Bedienungsanleitung Seite 56

EN
KEY FUNCTIONS ON THE CONTROL UNIT
SWITCH ON/OFF FREE ENTRANCE MODE
1
SWITCH ON FREE ENTRANCE MODE – PRESS BUTTON
Hold button 1 until the blue LED starts flashing.
2
THE ADMINISTRATOR CONFIRMS THE OPERATION
WITH HIS FINGERPRINT.
For security reasons, the administrator must always confirm the
operation.
AS LONG AS THE FREE ENTRANCE MODE IS ON, THE GREEN
LED SHINES.
3
SWITCH OFF FREE ENTRANCE MODE – PRESS BUTTON
Hold button 1 until the green LED is replaced by the blue one.
TURNING THE BLUE BACKLIGHT ON/OFF
HOLD BUTTON
TO ACCESS THE BUTTON, UNSCREW THE BOLT FIRST.
PRESS THE R
Violet LED flashes 5 times and you hear 5 beeps. All fingerprints
stored in the memory, including administrator fingers, will be
erased and the device will be reset to factory settings.
106
2 UNTIL THE BLUE LED IS TURNED ON/OFF.
FACTORY RESET
BUTTON AND HOLD IT FOR 10 SECONDS.
1
BLUE
A
GREEN
CONNECTION TO THE READER (ANDROID) WITH AN ADDITIONAL DEVICE
1
A SINGLE READER CAN BE CONNECTED TO MORE THAN ONE DEVICE (X-MANAGER APP)
BLUE
When adding a new device, it is necessary to turn off the Wi-Fi on devices that have already been
added, if they are nearby, otherwise they will try to connect and disable the addition of the new
device.
BLUE
VIOLET Press the i icon next to the name of the reader on the device which has
5 x
already established connection with the reader.
1
The password will appear on the lower portion of the screen. Write it
down.
On the new device, press Search, and in the next step, choose the
2
option MANUAL. When prompted, enter the name and the previously
retrieved password of the reader.
CONNECTING TO THE READER (ANDROID)
EVERY NEW READER NEEDS TO BE ADDED IN THE
X-MANAGER APPLICATION, BEFORE IT CAN BE USED. IF
MORE THAN ONE READER IS CONNECTED TO A SINGLE
X-MANAGER APPLICATION, IT IS IMPORTANT THAT THE
FIRST CONNECTION IS ESTABLISHED WITH ONE READER
AT A TIME. THE REST OF THE READERS SHOULD NOT BE
CONNECTED TO A POWER SUPPLY AT THE TIME OF THE
FIRST CONNECTION.
1
Press Search.
Enter the name of the device
2
and press ADD.
1
EN
2
107
