CONTROL WITH APPLICATION
Control with application on a smartphone:
Download the X-manager application to your smartphone or tablet from Google play or
the App Store.
Perform a factory reset and add the reader to the X-manager application. Connect it to the application and
then start entering administrator fingerprints into the application.
THE DEFAULT LANGUAGE OF THE APPLICATION IS THE SAME THAT YOUR OPERATING
SYSTEM (ANDROID OR APPLE) IS USING. IF X-MANAGER DOES NOT RECOGNISE YOUR
SYSTEM'S LANGUAGE, ENGLISH WILL BE USED.
1. Press the "R" button on the DIN control unit and hold it for 10 seconds.
2. To access the button on the door leaf control unit, unscrew the bolt first. Press the "R" button and
hold it for 10 seconds.
3. There are several options on the BBX mini control unit:
• FACTORY RESET BUTTON:
Press and hold the button for 10 seconds. After 10 seconds, when you hear a beep, you can release the
button. After that, violet LED flashes 5 times and you hear 5 beeps. This means that factory reset has been
successfully performed. All fingerprints stored in the memory, including administrator fingers, will be erased
and the device will be reset to factory settings. Connection with the mobile phones/devices will be lost.
After this operation, mobile phone must be paired first.
• RESET THE DEVICE WITH DOORPHONE SIGNAL WIRE:
When the signal wire for opening the door of the door phone is connected to + on the power supply
for 60 sec., all fingerprints stored in the memory, including administrator fingers, will be erased and the device
will be reset to factory settings. Connection with the mobile phones/devices will be lost.
After this operation, mobile phone must be paired first.
• RESET THE DEVICE WITH THE APP:
By clicking on the field "FACTORY RESET" all fingerprints stored in the memory, including administrator
fingers, will be erased and the device will be reset to factory settings. Connection with the mobile phones/
devices will be lost.
After this operation, mobile phone must be paired first.
FIRST CONNECTION TO THE READER
IT IS MANDATORY TO PERFORM FACTORY RESET BEFORE FIRST CONNECTION.
104
FACTORY RESET
WHEN X-MANAGER APP WILL CONNECT TO A READER FOR THE FIRST TIME (BEFORE
PAIRING), THE ORANGE LED WILL BLINK TEN TIMES. IF THERE ARE MORE READERS IN RANGE
(NONE OF THEM PAIRED), ORANGE LED WILL ALSO INDICATE TO WHICH OF THE DEVICES X-MANAGER
HAS BEEN CONNECTED. ONCE THE READER IS PAIRED, THERE WILL BE NO MORE INDICATION WHEN
THE CONNECTION IS ESTABLISHED.
THE READER ON WHICH FACTORY SETTINGS HAVE BEEN RESTORED WILL STILL BE
VISIBLE ON THE LIST OF READERS IN THE X-MANAGER, BUT IT CANNOT BE CONNECTED
ANYMORE. THE READER MUST BE DELETED FROM THE LIST AND THEN ADDED AGAIN.
THE READER AND THE CONTROL UNIT PAIRING
If the reader is replaced, the new unit needs to be paired with the control unit first:
1. Press and hold button "R" on the position 10 on the DIN control unit for 1 second.
2. First unscrew the security bolt over the button "R" on the door leaf control unit. Then press the
button and hold it for 1 second.
3. BBX mini control unit: After one second, you hear a short beep, and then you can release the button. When
you hear a longer beep, it means that the new reader and control unit have been paired.
THIS STEP PREVENTS UNAUTHORISED PERSONS FROM REPLACING THE EXISTING
READER WITH THEIR OWN AND THUS GAINING ACCESS.
FINGERPRINT READER SECURITY LOCKDOWN
In the case of the sensor not recognizing a fingerprint 7 times in a row, your fingerprint reader performs a 30 second
security lockdown. You are not able to use your device for this period but it will come back online after 30 seconds.
In case of additional 7 failed attempts, your fingerprint reader performs a lockdown again, this time for 60 seconds.
For every following sequence of 7 failed attempts, the lockdown period is extended for additional 30 seconds. The
longest lockdown period is 5 minutes. Whenever a finger print is recognised, the countdown towards lockdown is
reset.
WHILE YOUR FINGERPRINT READER IS IN LOCKDOWN, VIOLET LED IS BLINKING
CONTINUOUSLY. YOU ARE NOT ABLE TO USE YOUR DEVICE DURING THIS PERIOD.
Our fingerprint readers in combination with a DIN control unit or a control unit that is built into the profile of the door
allow you to unlock additional (side or garage) doors, as well as the door on which the reader is installed. Individual
fingerprints can be assigned to open either an additional door, or the main and an additional door together.
THE RELAY 2
