USER DELETION PROCEDURE
1
TO DELETE A USER'S FINGERPRINT, FIRST BUTTON
SHOULD BE PRESSED.
The blue LED will start blinking.
2
ADMINISTRATOR FINGERPRINT IS VERIFIED FIRST.
For security reasons an admnistrator fingerprint is
needed to start the user deletion procedure. When the
administrator's finger will be recognized, the green LED
will flash, accompanied by a beep.
If a non-administrative finger will be placed on the
sensor, the device will not react and the blue LED will
keep flashing.
3
1x
GREEN AND RED LEDS WILL FLASH ALTERNATELY.
THE FINGER THAT NEEDS TO BE DELETED SHOULD
BE PLACED ON THE SENSOR.
Successful deletion will be confirmed by 3 flashes of the
orange LED, accompanied by three beeps.
If a non-stored fingerprint will be placed on the sensor, the
device will not react. Green and red LEDs will keep flashing.
FACTORY RESET ON THE DIN CONTROL UNIT
1
BE PRESSED AND HELD FOR 10 SECONDS.
AFTER THIS PERIOD VIOLET LED WILL FLASH 5
TIMES AND 5 BEEPS WILL BE HEARD.
All fingerprints will be deleted from the database and
the device will have the factory settings restored. All
paired remote controls will be unpaired.
100
B ON THE CONTROL UNIT
BUTTON R ON THE CONTROL UNIT SHOULD
If the door on which the fingerprint reader is installed also has LED lighting, you can set the brightness of the
LED lighting with the X-manager application.
Adjustment may be required due to various possible positions of the photosensor, or in case the door is
BLUE
mounted in shadow or in a dark space.
Instructions for operation can be found in the
A
GREEN
1x
BLUE
RED
GREEN
2
U
ORANGE
3x
The reader does not need any special maintenance but the sensor should be always clean. If greasy or dirty
fingers are often used, the sensor becomes dirty and can begin performing poorly. The sensor should be gently
cleaned with a soft and damp cloth.
VIOLET
ANY AGGRESSIVE SOLUTIONS, ACIDS, POLISHING PASTES OR ABRASIVE CLEANERS
5x
SHOULD NEVER BE USED FOR CLEANING THE FINGERPRINT READER. RUBBING THE
SENSOR WITH HARD AND SHARP OBJECTS CAN LEAD TO SENSOR MALFUNCTION AND
CONSEQUENTLY LOSS OF WARANTY.
LED PHOTOREGULATOR
HYBRID CONTROL section.
SWITCHING THE BLUE BACKLIGHT LED OFF/ON
1
BUTTON 1 ON THE CONTROL UNIT SHOULD BE PRESSED AND HELD
FOR 10 SECONDS. 3 SHORT BEEPS WILL BE HEARD AND THE BLUE LED
WILL BE SWITCHED OFF.
Blue LED will start blinking but the button should not be released until three beeps
are heard. There is an option to turn off the blue LED which is continuously shining
while deviec is in stand by mode. Performing this operation will not turn off other
light signals. The same procedure should be used to switch the blue LED back on.
DOOR OPENING WITH A REMOTE CONTROL
The doors can be unlocked with a remote con-
trol (if included in the package). By pressing D
button, front door will unlock and by pressing C
1
button relay 2 will be triggered.
MAINTENANCE
