Assembly - Scheppach 4906807901 Original Bedienungsanleitung

Sound pressure level idle mode L
Sound pressure level during work L
Uncertainty K
pA
Sound power level idle mode L
Sound power level during work L
Uncertainty K
WA

8. Assembly

8.1 Column (5) and base plate (1) (Fig. 2)
1. Set the base plate foot (1) down on the floor or the
workbench.
2. Place the column (5) on the base plate (1) so that
the holes on the column (5) align with the holes on
the base plate (1).
3. Screw the three screws (6) to fasten the column (5)
into the base plate (1) and tighten them using an
open-ended spanner (size 13).
8.2 Removing the toothed rack (4) (Fig. 3)
In order to be able to install your drill, you must first
remove the toothed rack (4).
1. Use an Allen key (size 3) to remove the ring (7) and
pull this off the column (5).
2. Now pull the toothed rack (4) out.
8.3 Pre-installing the drilling table holder
(Fig. 17+18)
1. Push the crank holder (22) through the hole in the
drilling table holder (2) from the inside.
2. Put the crank handle (21) on the crank holder and
use the Allen key to secure the crank handle (3).
8.4 Installing the drilling table holder (2) (Fig. 4)
1. Insert the toothed rack (4) into the groove on the
drilling table holder (2).
2. Align the toothed rack (4) centrally in relation to the
drilling table holder (2).
3. When bringing the toothed rack (4) together with-
in the groove, ensure that the tooth meshing be-
tween the toothed rack (4) and the drilling table
holder (2) is correct.
4. Now place the drilling table holder (2) with the
toothed rack (4) on the column (5) and guide the
toothed rack (4) into the bottom rack guide on the
column foot.
32 | GB
70.7 dB (A)
pA
73.9 dB (A)
pA
3 dB
82.8 dB (A)
WA
86 dB (A)
WA
3 dB
www.scheppach.com
5. Use the ring (7) to secure the toothed rack (4). En-
sure that the toothed rack guide on the ring (7) is
pointing downwards. Tighten the integrated grub
screw to affix the ring (7).
6. Connect the adjustment handle for height adjust-
ment (3) to the drilling table holder's shaft (2) and
use a grub screw to secure it.
8.5 Installing the machine head (8) and column
(5) (Fig. 5)
1. Place the machine head (8) on the column (5).
2. Align the drill's spindle (33) with the drilling table
(18) and the base plate (1), and tighten the 2 grub
screws located on the side of the machine head
(8). (Size 4 Allen key)
8.6 Installing the chuck guard holder (16) (Fig. 6)
1. Place the chuck guard (16) on the spindle tube and
tighten the slotted screw (17).
8.7 Installing the handles (9) on the vertical
drive's crank (Fig. 7)
1. Screw the handles (9) tight in the spindle hub's
thread.
8.8 Installing the sprocket chuck (23) (Fig. 8)
1. Clean the conical hole in the sprocket chuck (23)
and the spindle cone with a clean piece of fabric.
Ensure that no particles of dirt remain on the sur-
face. The smallest amount of contamination on
one of the surfaces prevents the sprocket chuck
(23) holding properly. This can cause the drill bit
to wobble. If the conical hole in the sprocket chuck
(23) is extremely contaminated, use a cleaning
agent on a clean piece of fabric.
2. Push the sprocket chuck (23) onto the spindle
nose as far as possible.
3. Turn the outer ring on the sprocket chuck (23)
counterclockwise (when viewed from above) and
open the jaws on the sprocket chuck (23).
4. Place a piece of wood on the machine table and
lower the spindle (33) until it touches the piece of
wood. Press tight so that the chuck is secure.
8.9 Install the box column drill on the workbench
Screw the drill tight to a workbench using the holes on
the base plate (1) in order to prevent the machine tilting.
However, for your own safety, a screw connection on a
workbench or similar is strongly recommended.
