• Do not allow any lubricants to come into contact with
switches, V-belts, drive pulleys and drill lifting arms.
Lubrication
All ball bearings are greased in the factory so that
re-greasing is not required.
Lubricate all grooves in the spindle (33) and the toothed
rack (4) regularly.
To lubricate the drive, move the axle down and insert
the grease into the spindle (33) from above (below the
top cover). Move the axle up and down a few times.
To lubricate the toothed rack (4), move the axle down
and grease the axle's outer surface.
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consuma-
bles.
Wearing parts*: carbon brushes, V-belts, batteries, drill
bits
* may not be included in the scope of supply!
Spare parts and accessories can be obtained from our
Service Centre. Spare parts and accessories can be
obtained from our Service Centre.

13. Storage

Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the power tool in its original packaging.
Cover the power tool to protect it from dust or moisture.
Store the operating manual with the power tool.

14. Electrical connection

The electrical motor installed is connected and ready
for operation.
The connection complies with the applicable VDE and
DIN provisions.
The customer's mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
Damaged electrical connection cables
The insulation on electrical connection cables is often
damaged.
36 | GB
Causes are:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must
not be used and are life-threatening due to the in-
sulation damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking "H 07 RN".
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 230 volts/50 Hz.
• Extension cables up to 25 m long must have a cross
section of 1.5 square millimetres, and those over
25 m long must have a cross section of at least 2.5
square millimetres.
• The mains connection is protected with a 16 A slow-
blow fuse.

15. Disposal and recycling

The device is supplied in packaging to avoid
transport damages. This packaging is raw ma-
terial and can thus be used again or can be
reintegrated into the raw material cycle.
The device and its accessories are made of
different materials, such as metals and plas-
tics. Take defective components to special waste dis-
posal sites. Check with your specialist dealer or munic-
ipal administration!
