Wiring diagram

Introduction This section contains the electrical wiring diagrams for the main parts:
Schematic This illustrates the various pins for the main parts
J3 Relay outlet for failure – Contact specification: 5 A, 240 VAC:
PIN No.
1
2
J8 Input for option (humidistat):
PIN No.
1
2
3
4
Specification
Failure contact, normally closed
Failure common
Specification
-
-
12 VDC
Humidistat
PIN No. Specification
3 -
4 Failure contact, normally open
PIN No. Specification
5 -
6 -
7 -
8 -
