cable is mandatory.
AC motor
• The mains voltage must be 230 V~
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm .
2
Connections and repairs of electrical equipment
may only be carried out by an electrician.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Machine data - type plate

14. Troubleshooting

Fault

Possible cause

Motor does not work Motor, cable or plug defective, fuses burnt
The motor starts up Voltage too low, coils damaged, capacitor
slowly and does not burnt
reach operating speed.
Motor makes excessive Coils damaged, motor defective
noise
The motor does not Circuits in the network are overloaded (lamps,
reach its full power. other motors, etc.)
Motor overheats easily. Overloading of the motor, insufficient cooling
of the motor
Reduced cutting power Saw blade too small (ground too much)
when sawing
Saw cut is rough or Saw blade dull, tooth shape not appropriate
wavy for the material thickness
Workpiece pulls away Excessive cutting pressure and/or saw blade
and/or splinters not suitable for use
28 GB

13. Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in this
packaging can be reused or recycled. The equipment
and its accessories are made of various types of mate-
rial, such as metal and plastic. Defective components
must be disposed of as special waste. Ask your dealer
or your local council.
Remedy
Arrange for inspection of the machine by a special-
ist. Never repair the motor yourself. Danger! Check
fuses and replace as necessary
Contact the utility provider to check the voltage.
Arrange for inspection of the motor by a special-
ist. Arrange for replacement of the capacitor by a
specialist
Arrange for inspection of the motor by a specialist
Do not use any other equipment or motors on the
same circuit
Avoid overloading the motor while cutting, remove
dust from the motor in order to ensure optimal cool-
ing of the motor
Readjust end stop of the saw unit
Resharpen saw blade and/or use suitable saw
blade
Insert suitable saw blade
