Scope Of Delivery; Technical Data; Technical Specifications - EOS Moment Control W Montage- Und Gebrauchsanweisungen

The following are included in the scope of delivery:
• Sauna heating appliance
• Accessories bag with:
1 pc. cable gland with counter nut
6 pcs. screws 5 x 25 mm
4 pcs. self-tapping screws B 4.2 x 9.5
6 pcs. fillister head screws M 4 x 12
1 pcs. 3-pole connection comb (only by 6 / 7,5 kW)
• Wall-mounting support left 6 cm
• Wall-mounting support right 6 cm
• Hot air deflector

Technical specifications

Power
Electr. connection
Fuse protection
Equipment size (H x W x D)
For sauna cabin size
Min. size air supply and duct vent
Weight without stones and packing
Stone filling
Connection mains - heater
Leakage current
Control unit
Temperature control range
Temperature sensor
Intended use
All cross sections of a line are minimum diameters in mm² (Copper line).
ATTENTION! Installation - 22 cm floor gap to be observed!
26
9.0 kW
400 V 3N AC 50 Hz
3 x 16 A
64 x 44 x 33 cm
9 - 14 m³
35 x 6 cm
13.5 kg
15 kg (not included)
5 x 1.5, max. 10 m
max. 0.75 mA per kW of heating power
built in
40 - 100 °C
capillary sensor, built in
Sauna heater for use in private saunas
EN
