Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
we wish you a pleasant and successful working experience
with your new machine.
Note:
According to the applicable product liability law the man-
ufacturer of this device is not liable for damages which
arise on or in connection with this device in case of:
• improper handling
• non-compliance with the instructions for use
• repairs by third party, non authorized skilled workers
• installation and replacement of non-original spare
parts
• improper use
• failures of the electrical system due to the non-
compliance with the electrical specifications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
Recommendations:
Read the entire text of the operating instructions prior to
the assembly and operation of the device.
These operating instructions are intended to make it eas-
ier for you to get familiar with your device and utilize its
intended possibilities of use.
The operating instructions contain important notes how to
work safely, properly and economically with your machine
and how to avoid dangers, save repair costs, reduce down-
time, and increase the reliability and working life of the
machine.
In addition to the safety regulations contained herein, you
must in any case comply with the applicable regulations of
your country with respect to the operation of the machine.
Put the operating instructions in a clear plastic folder to
protect them from dirt and humidity, and store them near
the machine. The instructions must be read and carefully
observed by each operator prior to starting the work. Only
persons who have been trained in the use of the machine
and have been informed on the related dangers and risks
are allowed to use the machine. The required minimum
age must be met.

General Notes

• When you unpack the device, check all parts for possible
transport damages. In case of complaints the supplier
is to be informed immediately. Complaints received at
a later date will not be acknowledged.
• Check the delivery for completeness.
• Read the operating instructions to make yourself
familiar with the device prior to using it.
• Use only original parts for accessories as well as for
wearing and spare parts. Spare parts are available from
your specialized scheppach dealer.
• Specify our part numbers as well as the type and year
of construction of the device in your orders.
8 english
SLIK 7
Scope of delivery
Belt grinding machine
Grinding belt cover front
Grinding belt cover rear
Grinding rollers D 40/53/78
Cross table inserts 43/56/81
Longitudinal stop 550 x 175 mm
Chisel edge template 30° - 90° - 30°
Specifications
Dimensions
L x W x H mm
Longitudinal table
L x W mm
Cross table
L x W mm
Table height mm
Adjustment
grinding rest
Grinding belt
length/width mm
Grinding rest mm
Grinding belt
granulation
Belt speed m/sec
ø Suction
connector mm
Weight kg
Drive
230–240/50
Motor V/Hz
2,46
Input P1 kW
1,90
Output P2 kW
Operating mode
1420
Rotational speed
Undervoltage
ja
release
Schuko
Plug
Subject to technical modifications!
Noise parameters according to EN 23746
The noise emission values determined according to
EN 23746 for the sound power level or according to
EN 31202 (correction factor k3 calculated according to
Annex A.2 of EN 31204) for the sound level at the work
place are based on the working conditions specified in
ISO 7960 Annex A and are as follows:
Sound power level at the work place in dB
Idle running L = 77.0 dB(A)
WA
Processing L = 87.0 dB(A)
WA
Sound level at the work place in dB
Idle running L = 69.0 dB(A)
pAeq
Processing L = 77.0 dB(A)
pAeq
A measuring incertainty allowance K=4 dB applies for the
specified emission values.
Specifications regarding the dust emission
The dust emission values that were measured according
to the "Principles for the evaluation of the dust emission
(concentration parameters) of wood working machines" of
the Fachausschuss Holz (Expert committee wood) are be-
low 2 mg/m . Thus, it can be assumed that the TRK limit
3
value for wood dust applicable in the Federal Republic of
Germany is permanently and reliably fallen short of when
the machine is connected to a proper operational suction
Work piece stop
Suction connector
Grinding belt
Assembly tools
1540/700/1215
900/305
290/225
904 – 1020
0 – 90
2740/150
900
80
16
100
225
400/50
2,85
2,25
1420
ja
CEE
