Figure
in the seat. Place the two buckle latches together and then
Fig. 4.
connect the visible metal part to the buckle. Lock the system
Fig. 5.
by tipping it forwards slightly. An audible click will be heard.
Check that the belts are not twisted.
Fig. 6.
Only if the harness straps are positioned correctly and secu-
rely will your child have optimum protection. Therefore the
belt length should be correct when your child wears different
clothing. Tighten the sytem by pulling the belt on the central
adjuster (M). Ensure that the cover does not become jammed
beneath the adjustment button so that the blocking function
is not impaired. To remove the child release the belt system
by pushing the red buttom.
The lap belt and the buckle should lie against the child's body
in the lowest position possible.
Fig. 6. Selection of suitable shoulder strap height
The height of the shoulder straps (E) must be adjusted to the
body size of the child. The belts should be threaded through
the slots in the back rests (B) as close to the shoulder height
of the child as possible.
As a guide to this:
B1: Bottom shoulder strap slots for children up to approx.
2 years of age
B2: Middle shoulder strap slots for children up to approx.
4,5 years of age
B3: Top shoulder strap slots for children up to approx.
6 years of age
The straps are released and secured by removing or attaching
the shoulder strap loops to the yoke (G). Ensure that the
straps are correctly inserted and are not twisted.
Please ensure that the crotch belt with lock (L) passes
through the front opening, from above, and through the back
opening from below. The metal plate at the end of the belt
must be in the back opening, at the top.
Reclined Position
The reclined position for the FixMax child seat allows child-
Fig. 7.
ren between approx. 9 month and 4 years (9 - 18 kg) to travel
even more comfortably in a sleeping position. The reclined
position wedge required for this is available as an accessory.
11
short version
Move belt off the seat
Move buckle forwards
Check belts
Length adjustment
Remove the child
Adjust height of the shoulder
straps to the size of the child
