Figure Using the FixMax as a child seat
Congratulations on your purchase of our CONCORD FixMax
seat to secure your child. This product is manufactured in
compliance with a strict system of quality control. It can only
develop it's optmum safety features if it is used properly and
you should therefore follow these instructions for fitting and
use closely. The seat can be used on any seat in the vehicle
which has a three-point belt or a lap belt.
Accident statistics show that the safest place for it is behind
the front passenger seat.
When selecting the position for the child seat in your vehicle
always use the one which offers the best fitting results.
Fitting the seat using a three-point belt
Fig. 1.
Thread the buckle latch on the three-point belt through the
slot in the back rest (D) and close the seat belt in the same
way as for an adult. If the buckle strap is too long, use the
buckle from the next seat. Thread the diagonal belt into the
Fig. 2. belt clamp. Press the seat firmly into the upholstrery and pull
the diagonal belt tight. The lap belt on the three point belt
must also be tight. The belt clip (C) thus ensures that the
seat is fitted securely. Ensure that the belt is not twisted and
is tight throughout. By raising the back rest cover you can
check the position of the belt and retension it if necessary. If
the belts do not run at an angle backwards, fit the seat using
the lap belt. If the seat is fitted on the front passenger seat,
the passenger seat can be moved further forwards.
Fitting the seat using a lap belt
Fig. 3. The child seat can also be fitted on a static lap belt (without
an automatic retractor). Thread the latch for the static lap
belt through the aperture (D) in the back rest and close the
lap belt in the same way as for an adult. Press the seat firm-
ly into the upholstery and pull the lap belt tight. By raising
the back rest cover you can check the position of the belt and
retension it if necessary. Spare lap belts are available from
the trade for retrofitting.
Securing your child
Lengthen the straps by pushing the button on the central adju-
ster (M) and pulling the shoulder strap (E). Pull the two buckle
latches (H) off the seat and the buckle forwards. Sit your child
short version
Insert the three-point belt
Lock three-point belt
Insert diagonal belt into the
belt clip
Pull diagonal belt thight
Check the belt
Insert static lap belt
Close lap belt
Tighten lap belt
Check belt
