A back rest
B shoulder strap slots
B3 top: for children up to 6 years
B2 middle: for children up to 4,5 years
B1 bottom: for children up to 2 years
C belt clamp
D belt aperture
E shoulder straps
F lap strap
9
English E
CONCORD FixMax
Fitting the seat using a three-point belt
Fitting of the seat using a lap belt
Securing the child
Selection of suitable shoulder straps
Lying position
How to convert the FixMax into the Image
booster cushion
CONCORD Image
The Image as a booster cushion
Fitting using a three-point belt
Care instructions
Important information
Guarantee
G lap strap
H five-point buckle
I connecting screws on both sides, see also fig. 8
K Image seat
L scrotch strap with latch
M central adjuster with one-pull adjuster strap
N belt apertures for the three-point seat
belt for using the Image booster cushion
page 10
page 10
page 10
page 11
page 11
page 12
page 12
page 13
page 13
page 13
page 15
