GB
Figure Fitting using a three-point belt
Now thread the belt into the belt apertures (N) for it in the
sides of the booster cushion. The bottom section of the
diagonal belt must be threaded through the belt aperture (N)
together with the lap belt. The top section passes between
the shoulder and neck of the child. If the height of your car
seat belt can be adjusted, move it to a suitable height.
Tighten the belt so that the lap belt and shoulder belt are
always in close contact with the body and are not twisted.
Care instructions
To remove the cover for washing: The seat cover can simply
be taken off upwards after removing the belt. During
assembly ensure that the belt runs downwards into the front
aperture and it fed into the bottom aperture from below with
the end fitting lying flat in the rear recess on the top. The
belt must not be twisted. The cover on the back rest at the
bottom on both sides. Do not use solvents to clean the cover.
• When washed or in contact with any moisture, the cover
fabric may fade slightly.
13
!
short version
Thread belt into belt apertures
Check belt
Care instructions
30°
