It is very easy to use:
The wedge-shaped reclined position accessory is simply
placed between the FixMax child seat and locked into place
in the recess designed for it. Ensure that the lap strap on the
five-point system is in the resess for it and the belts are not
twisted.
Note:
Do not use the IMAGE booster cushion with the reclining
wedge.
How to convert the FixMax into the Image booster
cushion
The back rest can be removed at any time when the child's
body weight is between 15 and 25 kg. For children who fre-
quently fall asleep during car journeys the back rest and the
shoulder straps offer good support. We recommend that the
back rest is removed when the child is around 5 or 6 (approx.
20 kg). When the child's eyeline is at the top of the back rest
or the weight of the child exceeds 25 kg the back rest must
be removed.
Loosen the plastic rivets or the seam at the end of the belt
on the central adjuster (M) and then pull the belt out to the
rear. Remove the belt system from the booster cushion by
threading the fittings through the apperture in the cushion.
To remove the back rest from the booster cushion first
Fig. 8. remove the cover from the back rest at both sides. The
screws which then become visible (I) are to be removed with
a screwdriver. The back rest can now be removed backwards.
Please pay attention to the fact that the lap strap of the five-
point belt system is placed in the appropriate gaps and is not
twisted.
Tip: The reclining wedge cannot be used in connection with
the booster seat Image.
Using the Image as a booster cushion
The cushion can be used on any of the seats in the car wich
has a three-point belt. Accident statistics show that the
safest place for it is behind the front passenger seat.
Fig. 9. Place the Image on the seat and place your child on it. Fasten
the three-point seat belt in the same way as for an adult.
short version
Place reclining accessory
beneath the child seat and lock
into place
Check belts
Note:
In order to optimise the
protective effect, we
strongly recommend the
use of the IMAGE booster
seat with the optional
LIFT backrest.
Remove belt system
Remove the cover from the
back rest
Remove the screws
Remove back rest
Seat behind the front
passenger seat
Place child on cushion
Fasten three-point seat belt
