Page EN-12
Appliance parts
Appliance parts
Appliance and charging station
(1)
(2)
(3)
(7)
(8)
(9) (8)
(5)
(10)
(11)
(13)
(15)
(4)
(6) (5)
(5)
(10)
(1)
(12)
(17)
(14)
(16)
(1)
Dust bin
(2)
Release button for dust
bin
(3)
Motor housing
(4)
Control panel
(5)
Dust brush
(6)
Orientation sensor
(7)
On/Off switch
(8)
Charging contacts
(9)
Steering wheel
(10) Driving wheel
(11) Roller-brush
(12) Charging station
(13) Charging contacts charg-
ing station
(14) Operational control dis-
play
(15) Socket
(16) Appliance plug
(17) Mains power adapter
