CVM-E3-MINI
DESCRIPTION
Potencia activa
Potencia reactiva
Factor de potencia
Tensión fase-neutro
Corriente
Potencia activa
Potencia reactiva
Factor de potencia
Potencia activa trifá-
sica
Potencia inductiva
trifásica
Potencia capacitiva
trifásica
Cos φ trifásico
Factor de potencia
trifásico
Frecuencia (L2)
Tensión fase-fase
Tensión fase-fase
Tensión fase-fase
%THD V
%THD V
%THD V
%THD A
%THD A
%THD A
Energía activa
Energía reactiva in-
ductiva
Energía reactiva capa-
citiva
Energía Aparente
trifásica
Energía activa gene-
rada
Energía inductiva
generada
Energía capacitiva
generada
Energía aparente
generada
Máxima demanda
kvarL
Potencia aparente L1
Potencia aparente L2
Potencia aparente L3
Betriebsanleitung
Active power
Reactive power
Power factor
Voltage phase to
neutral
Current
Active power
Reactive power
Power factor
Three phase active
power
Three phase reactive
inductive power
Three phase capacitive
inductive power
Three phase cos φ
Three phase power
factor
Frequency
Voltage phase to phase
Voltage phase to phase
Voltage phase to phase
%THD V
%THD V
%THD V
%THD A
%THD A
%THD A
Active energy
Reactive inductive
energy
Reactive capacitive
energy
Three phase aparent
energy
Three phase generated
active energy
Three phase genera-
ted reactive inductive
energy
Three phase genera-
ted reactive capacitive
energy
Three phase generated
aparent energy
Maximum demand
kvarL
Aparent power L1
Aparent power L2
Aparent power L3
SYMBOL ID OBJECTS OBJECT NAME
kW 2 AI7
kvar 2 AI8
PF 2 AI9
V 3 AI10
A 3 AI11
kW 3 AI12
kvar 3 AI13
PF 3 AI14
kW III AI15
kvarL III AI16
kvarC III AI17
Cos φ III AI18
PFIII AI19
Hz AI20
V12 AI21
V23 AI22
V31 AI23
%THD V1 AI24
%THD V2 AI25
%THD V3 AI26
%THD A1 AI27
%THD A2 AI28
%THD A3 AI29
kW•h III AI30
kvarL•h III AI31
kvarC•h III AI32
kVA•h III AI33
kW•h III (-) AI34
kvarL•h III (-) AI35
kvarC•h III(-) AI36
kVA•h III (-) AI37
kvarL III AI38
kVA AI40
kVA AI41
kVA AI42
UNITS
ActPwrPh2 kW
ReactPwrPh2 kvar
PwrFactPh2 PF
Ph2NU3 V
Ph3Current A
ActPwrPh3 kW
ReactPwrPh3 kvar
PwrFactPh3 PF
ActPwOn3Ph kW
InductPwOn3Ph kvarL
CapPwOn3Ph kvarC
Cosphi Cos φ
PwFactOn3Ph PF
Frequency Hz
Ph2PhU12 V
Ph2PhU23 V
Ph2PhU31 V
THDVal_U1 %THD
THDVal_U2 %THD
THDVal_U3 %THD
THDVal_I1 %THD
THDVal_I2 %THD
THDVal_I3 %THD
ActEnergy kW•h
InductEnergy kvarL•h
CapEnergy kvarC•h
AppEnergy kVA•h
ActEnergy_exp kW•h
IndEnergy_exp kvarL•h
CapEnergy_exp kvarC•h
AppEnergy_exp kVA•h
MaxDemand_
kvarL
kvarL
AppPwrPh1 kVA
AppPwrPh2 kVA
AppPwrPh3 kVA
