KCI V.A.C.ULTA Update-Anleitung Seite 13

V.A.C.® Therapy Alarm Testing
1. Attach the test canister with tubing and the V.A.C. VERAFLO™ test fixture to the unit.
2
3
4
5
• Verify the test canister is latched correctly
• Set V.A.C. VERAFLO™ test fixture on the unit.
• Only set the test fixture on the unit, do not engage
• Connect the twist lock connector
2
3
0 0 : 0 0 : 4 5
4
5
2. Press the Arrow button displayed next to
3. Engage fixture PN SE-001179, disengage and engage again.
4. Press the Arrow button displayed next to
Blockage Alarm.
5. Detach the test canister with tubing from the unit.
6. Detach V.A.C. VERAFLO™ Bracket Test fixture from the unit.
7. Press the Arrow button displayed next to
8. Attach the Canister Full Test Fixture to the unit.
9. Press the Arrow button displayed next to
Canister Full Alarm.
10. Detach the Canister Full Test Fixture from the unit.
Leak Alarm.
Canister Not Engaged Alarm.
13
