Note:

A connection via the RS232 interface can only be activated if "RS232" is selected in the
"COMMUN" menu.

The unit can be controlled completely over RS-232.

For more information, see the chapter 8.
16. USB-Interface (USB-B)
Use the USB interface to connect your device to a PC via direct data connection.
Note:

A connection via the USB interface can only be activated if "USB" is selected in the "COMMUN"
menu.

The unit can be controlled completely over USB.

You have to install working drivers for Windows

For more information, see the chapter 8.
17. Bluetooth™-Adapter Interface
Via the Bluetooth ™ interface, a wireless data connection to the meter with your PC via a Bluetooth
™ adapter can be created.
Note:

A connection via the Bluetooth ™ interface can only be activated if "BT" is selected in the
"COMMUN" menu.

The unit can be controlled completely over Bluetooth ™.

You have to install a working Bluetooth adapter to your PC-Systems before operation.

For more information, see the chapter 8.
18. LAN interface (RJ45)
Via the LAN interface (Local Area Network), the device can be directly connected to the PC or
integrated into the corporate network with a router.
Note:

The network connection must not be activated separately

A detailed guide to network settings, see the chapter 8
19. AC power connector
The power connector is used to connect the device with the power grid via a special plug with
earthing contact.
Note:

Only operate the device with a connected PE Contact
20. USB-DISK connector
The USB-Disk connection is used for direct data recording with the MEM function to an external USB
memory stick.
Note:

For saving data a suitable USB-Disc must be connected to the device

"USB DISC" must be selected in the MEM menu as the storage location

Readings can be stored until the media is full. Please refer to the chapter "MEM"-function
TM
Systems before operation.
