5. Click Configuration -> Configuration Parameters -> System tab -> Reset the Controller -
> Apply. The subsystem is reset.
6. Click Configuration -> Host LUN Mapping and change to new IDs.
7. Switch on the subsystem and then the Divar. The power switches of the subsystem are
located on the rear side of the unit.
To configure the Divar:
(Use the control elements on the front panel)
1. After the Divar has booted, press ALT+
The Divar opens the Main menu.
2. In the Main menu, use the arrow key (down) and move to Disk Manager. Then press
open the Disk Manager menu.
3. Use the arrow key (down) and move to STORAGE SETUP. Then press
Menu with the external drives and their SCSI IDs.
4. Use the arrow key (down) and move to the requested drive. Then press
5. Use the arrow key (up/down) and activate YES. Then press
6. Assign all drives in this way.
7. Press ESC. If the drive configuration has changed, the Divar opens the Restart Menu.
8. To accept the changes and to restart the system, use the arrow key (left) and move to
YES. Then press
NOTICE!
Alternatively you can use the Divar Control Center Software to change drive configuration.
Please refer to your Divar manual for more information.
