RAID Subsystem DVA-08E, -08K, -16K
Bosch Sicherheitssysteme GmbH
Downloaded from www.Manualslib.com
1 DiBos
2 RAID subsystem(s)
(no daisy chaining for DVA-08E)
3 SCSI port
4 CH0-IN
2. For daisy chaining several subsystems, you must switch off the termination of channel
CH0/1-OUT of all subsystems except the last.
Expand the configuration tree -> click Configuration -> Channel -> Channel 0 or
Channel 1 -> ID Tab -> Termination: Disabled -> Apply.
3. Click Configuration -> Configuration Parameters -> System tab -> Reset the Controller -
> Apply. The subsystem is reset.
4. For daisy chaining, change the CH0/1-OUT SCSI channel ID of the second subsystem.
Expand the configuration tree -> click Configuration -> Channel -> Channel 0 or
Channel 1 -> Parameters Tab -> for DVA-08K: clear the 0 and 1 check boxes and select
the 2 and 3 check boxes; for DVA-16K: clear the 0, 1, 2, and 3 check boxes and select the
4, 5, 6 and 8 check boxes -> Apply.
5. Click Configuration -> Configuration Parameters -> System tab -> Reset the Controller -
> Apply. The subsystem resets.
6. Click Configuration -> Host LUN Mapping and change to the new ID.
7. Switch on the subsystem and then the DiBos. The power switches of the subsystem are
located on the rear side of the unit.
To configure the DiBos 8:
1. In DiBos, log on in Windows as Administrator but do not start the DiBos application.
Refer to DiBos Installation Manual for more information.
2. Click the Start button, and then click Control Panel.
3. In Control panel, double-click Administrative Tools.
4. In Administrative Tools, double-click Computer Management.
5. In Computer Management, click Disk Management.
If the subsystem is properly connected, the Disk Manager starts the Initialize and
Convert Disk Wizard.
manuals search engine
5
6
7
Quick Installation Guide
Connecting a Digital Video Recorder | en
CH0-OUT
DVA-ACON-HD68A or cable
supplied with DiBos
DVA-ACON-VD68A or
DVA-ACON-VD680A
(SCSI connection)
F.01U.027.800 | V5 | 2010.06
