Typical Display
Currently
selected
material or
velocity of
material
Battery Icon
When a Menu option is highlighted, the
icon indicates on-gage help is available.
Press or touch the
help. A formatted PDF containing all on-
gage help items is available at
www.defelsko.com/help
NOTE:
Update your gage to ensure that you
have the latest on-gage help information.
indicates that a sub-menu exists for the
Menu option. Select the option to display its
sub menu.
The Coupled symbol appears
when the probe is ultrasonically
connected with a surface.
2
icon to display the
Measurement
Mode currently
set to multiple-
echo
(UTG M /
UTG P probes only)
Current
Measurement
Unit of
Measurement
