When powered up the PosiTector automatically
determines what type of probe is attached and does a
self-check.
To disconnect a probe from a body, slide the plastic probe
connector horizontally (in the direction of the arrow) away
from the body. Reverse these steps to attach a new
probe. It is not necessary to power-down the Gage when
switching probes.
Additionally, the PosiTector gage body accepts a wide variety of
probe types including magnetic, eddy-current, and ultrasonic
coating thickness, surface profile, environmental, hardness, salt
contamination and ultrasonic wall thickness probes. See
www.defelsko.com/probes
PosiTector UTG probes are available for a
variety of wall thickness applications:
• PosiTector UTG CA / UTG C – dual element, single-echo
probe ideal for measuring severely corroded/eroded materials.
PosiTector UTG CA models feature a built-in probe, while
PosiTector UTG C models feature a probe mounted on a 1 m
(3 ft) cable.
• PosiTector UTG CX - same specifications as UTG C above,
but includes a braided stainless steel cable jacket and
reinforced strain reliefs for protection in demanding
environments.
• PosiTector UTG CLF – dual element, single-echo probe
designed for measuring thick and/or attenuative materials such
as cast iron.
• PosiTector UTG M – single element, multiple-echo probe
features Thru-Paint capability designed to quickly and
accurately measure the metal thickness of a painted structure
without having to remove the coating.
• PosiTector UTG P – single element probe with automatic
single-echo or multiple-echo (Thru-Paint) mode depending on
material type and thickness. Ideal for high-resolution
measurements on thin plastics and metals.
Probes
3
