Securing workpiece on the faceplate:
Workpieces that cannot be worked using the head-
stock drive centre (3), instead must be mounted on a
faceplate (17) or a backing piece, such as a chuck or
block of wood.
1 Rough cut the workpiece as close as possible to
the final shape before mounting onto the face-
plate (17).
2 Firmly attach the faceplate (17) to the workpiece.
Depending on the workpiece, this can be done
with wood screws (not supplied) driven directly
into the workpiece. Where the intended cutting
dimensions do not allow for screws, a backing
piece might be required.
3 A backing piece can be made from a piece of scrap
wood cube with two flat and parallel opposite faces.
Identify and mark the centre of the backing piece.
The backing piece (chunk of wood block) may
need to be glued to the workpiece, and attached
to the backing piece which is then attached to the
faceplate (17) with screws (not supplied). In this
case, clamp the backing piece to the workpiece
and wait for the glue to dry according to the glue
manufacturer's recommendation. Where the use
of screws into the workpiece is not permissible,
the workpiece can be glued onto a backing piece
with a piece of paper placed in between the joint.
This allows for later separation without damage
caused to the workpiece. Use only non­tapered
head wood screws. Do not use tapered head
wood screws.
Caution: Pay attention to the wood turning chisel so
that it does not interfere with the holding screws at
the finished dimensions of the workpiece.
Switching on and off (Fig. 1)
• Press the On switch (2/green) to start the machine.
• Press the Off switch (2/red) to stop the machine.
Important information for operation
• We recommend that you refer to specialised litera-
ture on wood­turning techniques.
• Look out for knots and shrinkage shakes when
selecting the wood for your turning work. Only
use wood which is free of cracks and large knots
(where there are small knots, take appropriate care
with the pressure applied with the turning tool).
• Always check that the shaped item is securely held
by checking it by hand. Warning! Pull out the power
plug!
• Use only an original turning tool which is sharp.
• Do not stand in the flight path of the workpiece
when turning wooden disks.
• Please cut large and imbalanced shaped items to
size as best as possible using a bandsaw or fret-
saw.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
If the shaped items are very imbalanced they will
pose a risk to your health and to the service life
of the machine.
• Always start with the lowest possible speed for
new workpieces being turned and increase it with
increasing massiveness of the workpiece being
turned.
• Do not use wooden disks with contraction cracks,
since they pose a high risk of bursting under the
impact of centrifugal forces.
• Do not exceed the maximum workpiece sizes.
• In case of tools which get blocked: Pull out the
power plug first before starting troubleshooting.
• To do your turning work, position yourself at the
machine so that you can guide the cutting tools
effectively on the tool support.
• Only use cutting tools, which are recommended
for wood turning works.

9. Transport

If you want to move the equipment to a different
place, disconnect the equipment from the power sup-
ply and set it up in the new position you want to use
it in.

10. Cleaning and maintenance

Important.
Warning! Prior to any adjustment, maintenance or
service work disconnect the mains power plug!
General maintenance measures
Wipe chips and dust off the machine from time to
time using a cloth. In order to extend the service life
of the tool, oil the rotary parts once monthly. Do not
oil the motor.
When cleaning the plastic do not use corrosive prod-
uct.
Maintenance
• There are no parts inside the machine which re-
quire additional maintenance.
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Carbon brushes, v­belt,
* Not necessarily included in the scope of delivery!
