Current Loop Measurement 4...20 mA
Measurement Range: 4...20 mA corresponds to 0...100 %
Resolution: 0,01 %
Accuracy: ± 25 D
Temperature T1, T2 (only Hexagon 720)
Measurement Range Accuracy
-50,0...1000,0°C ± (0,3% rdg. + 1°C)
-58,0...1832,0°F ± (0,3% rdg. + 1°F)
Thermocouple accuracy is not taken into account.
Diode Test
Range Accuracy
5,0000 V ± (1% rdg.+1D)
Overload protection:
12 month Warranty
UNITEST instruments are subject to strict quality control.
However, should the instrument function improperly dur-
ing daily use, your are protected by our 12 months warran-
ty (valid only with invoice).
We will repair free of charge any defects in workmanship
or material, provided the instrument is returned unopened
and untampered with, i.e. with undamaged warranty label.
Any damage due to dropping or incorrect handling are not
covered by the warranty.
If the instrument shows failure following expiration of war-
ranty, our service department can offer you a quick and
economical repair.
Subject to changes without notice!
manuals search engine
Warranty
Overload Protection
600 V ACrms /DC (710)
1050 Vrms, 1450 Vss (720)
Test Current (typical) Test Voltage
0,8 mA <3,5 V DC
600 V ACrms /DC UNITEST Hexagon 710
1050 Vrms, 1450 Vss UNITEST Hexagon 720
