AC, AC+DC Voltage
Measurement Range
500,00 mV; 5,0000 V; 50,000 V
500,00 V; 1000,0 V
500,00 mV
5,0000 V; 50,000 V
500,00 V; 1000,0 V
500,00 mV
5,0000 V; 50,000 V; 500,00 V
1000,0 V
500,00 mV
5,0000 V; 50,000 V
500,00 V
1000,0 V
500,00 mV
5,0000 V; 50,000 V
500,00 V
1000,0 V
* specified for 5% to 10% of measurement range ± (% rdg. + 80 D)
** specified for 5% to 10% of measurement range ± (% rdg. + 180 D), for 5%
to 10% of measurement range ± (% rdg. + 100 D)
Overload protection: 1050 Vrms, 1450 Vss
CMRR: >90 dB(0...60 Hz, Rs= 1kOhm)
Input impedance: 10 MOhm, 30 pF nominal (80 pF nominal within 500 mV
measurement range)
