Installation of side panels
Side panels are optional accessories and can be mounted if required on 1 - 4 sides. The side panels
are not only a decoration element they will also significantly reduce the radiant heat. This allows
the reduction of the side safety gap to 5 cm (Fig. 8).
• First insert the bottom end
tongues of the panel into the
openings in the heater shell,
then put the upper part over
the top edge of the outer
shell (Fig .7).
• Secure each side panel with 2
supplied screws (Fig. 7).
• The safety gaps between the heater and the cabin wall, as well as the protective heater guard
rail, the bench and other flammable materials change to 5 cm (see Fig. 8)
34
(optionally available)
2
1
Guard rail
5 cm
5 cm
EN
Side panels
Fig. 8
Fig. 7
