Connection example for 230V 1N AC
Saunaofen / sauna heater
poêle de sauna /
max. 7,5 kW
L
230 V AC
N
PE (Gr)
Specifications for 230V 1N connection
Power output
7,5 kW
9,0 kW
All cross sections of a line are minimum diameters in mm² (Copper line).
All cross sections are given for 230V 1N power supply!
Zeitschaltuhr
timer
A
A1
A
A1
M
B
B1
L1 L2 L3
N
N
N
PE
6 mm² / 35 A
Electrical connection
Fuse protection
230 V 1N AC 50 Hz
Thermostat
Thermostat
A1
A2
A3
By 230V 1N connection the 3-pole
copper bridge must be fitted on
the U/V/W terminals. This bridge is
included in the delivery scope.
Connecting cable
mains - heater
1 x 35 A
1 x 35 A
EN
Sicherheits
temperaturbegrenzer
overheat safty
shutdown device
reset
B1
B2
B3
7,5 kW = 3x 1000 W + 3x 1500 W
9,0 kW = 6x 1500 W
3 x 6 mm²
3 x 6 mm²
31
