Filling The Sauna Rocks - EOS Edge Control Montage- Und Gebrauchsanweisung

Filling the sauna rocks

• Only fill the sauna heater when it is set up in its final position.
• Remove the centre console (protective grille).
• Fill the sauna stones in the lower area up to the centre console.
• Reinsert the centre console.
• Fill the upper area with sauna stones.
• Important! The heating elements has to be invisible through the stones from the outside.
• Important! Do not push or pull the stone-filled sauna heater across the floor. The feet could be
damaged.
Centre console
(protective grille)
Rock store
Attention! Risk of fire!
A visible heating element is a source of excessive heat and can endanger flammable
•
materials even beyond the safety gaps.
Make sure that no heating elements are visible from outside between the stones.
•
max.
min.
EN
Fig. 9
35
