Scope of delivery
Check the delivery contents and verify that all parts are available. Missing or damaged parts should
be reported to your authorized dealer.
The standard delivery includes:
• 1 sauna heater
• 1 accessories bag with:
4 floor-standing feet
4 nuts M8
1 cable gland with counter nut
1 pcs. copper jumper (bridge for 230V connection)
• Installation and operation manual
Technical Data
Elektrischer Anschluss
Ofenleistung nach DIN
für Kabinenvolumen
Mindestmaß der Be- und Entlüftung
Gewicht ohne Steine und Verpackung
Size (H x W x D)
Stone volume
Leakage current
Intended use
Temperature control range
Fuse protection
Connection power supply - heater
All cross sections of a line are minimum diameters in mm² (Copper line).
400 V 3N 50 Hz AC
(Connection to 230V 1N possible *)
7,5 kW
8 - 12 m³
35 x 5 cm
17 kg
~ 100 x 35 x 35 cm
(by optional side panels: +2,5 cm per each panel)
115 kg (not included)
max. 0,75 mA per kW heating power
Sauna heater for use in private saunas
40 - 100°C
3 x 16 A
5 x 1,5 mm², max. 10 m
EN
9,0 kW
9 - 14 m³
35 x 6 cm
29
