Gemü 567 BioStar control Betriebsanleitung Seite 24

5 Abmessungen
5.2.10 Clamp ohne Bypass Code 86
LE1
DN
Sitz- L
größe
(Code)
8 A 45
B 45
C 45
10 A 45
B 45
C 45
D 45
15 A 45
B 45
C 45
D 45
E 45
G 45
20 A 45
B 45
C 45
D 45
E 45
G 45
H 55
25 H 55
GEMÜ 567 BioStar control
L
H1
d1
d3
Anschlussarten Code 86
Werkstoffe Code 41, 43
□ E Ø z LE1
75 2 60,5
75 4 60,5
75 6 60,5
75 2 59,5
75 4 59,5
75 6 59,5
75 8 59,5
75 2 56,5
75 4 56,5
75 6 56,5
75 8 56,5
75 10 56,5
75 15 56,5
75 2 54,5
75 4 54,5
75 6 54,5
75 8 54,5
75 10 54,5
75 15 54,5
95 20 69,5
95 25 65,0
1)
2)
LE2 H1
73,5 17,5
72,5 17,5
71,5 17,5
74,5 18,5
73,5 18,5
72,5 18,5
71,5 18,5
77,5 21,5
76,5 21,5
75,5 21,5
74,5 21,5
73,5 21,5
71,0 21,5
79,5 23,0
78,5 23,0
77,5 23,0
76,5 23,0
75,5 23,0
73,0 23,0
85,5 23,0
88,0 28,1
24 / 45
H2 cz Ø d1
40,5 3,0 8,0
39,5 2,0 8,0
38,5 1,0 8,0
41,5 4,0 10,0
40,5 3,0 10,0
39,5 2,0 10,0
38,5 1,0 10,0
44,5 7,0 16,0
43,5 6,0 16,0
42,5 5,0 16,0
41,5 4,0 16,0
40,5 3,0 16,0
38,0 0,5 16,0
46,0 9,0 20,0
45,0 8,0 20,0
44,0 7,0 20,0
43,0 6,0 20,0
42,0 5,0 20,0
39,5 2,5 20,0
47,5 0,0 20,0
50,0 2,5 26,0
www.gemu-group.com
Ø d3
25,0
25,0
25,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
34,0
50,5
