Gemü 567 BioStar control Betriebsanleitung Seite 16

5 Abmessungen
5.2.2 Stutzen ohne Bypass Code 17
c
DN
Sitz- L
größe
(Code)
8 A 45,0
B 45,0
C 45,0
10 A 45,0
B 45,0
C 45,0
D 45,0
15 A 45,0
B 45,0
C 45,0
D 45,0
E 45,0
G 45,0
20 H 55,0
25 H 55,0
J 55,0
Maße in mm
1) Anschlussart
Code 17: Stutzen EN 10357 Serie A (ehemals DIN 11850 Reihe 2) / DIN 11866 Reihe A
2) Werkstoff Ventilkörper
Code 41: 1.4435 (316L), Vollmaterial
Code 43: 1.4435 (BN2), Vollmaterial, Δ Fe < 0,5 %
GEMÜ 567 BioStar control
L
s
LE
H1
d
□ E c
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
75,0 20,0
95,0 25,0
95,0 25,0
95,0 25,0
Anschlussarten Code 17 1)
Werkstoffe Code 41, 43 2)
Ø z LE H1
2,0 47,5 17,5
4,0 47,5 17,5
6,0 47,5 17,5
2,0 46,5 18,5
4,0 46,5 18,5
6,0 46,5 18,5
8,0 46,5 18,5
2,0 43,5 21,5
4,0 43,5 21,5
6,0 43,5 21,5
8,0 43,5 21,5
10,0 43,5 21,5
15,0 43,5 21,5
20,0 55,0 25,1
20,0 52,0 28,1
25,0 52,0 28,1
16 / 45
H2 cz Ø d
40,5 3,0 10,0
39,5 2,0 10,0
38,5 1,0 10,0
41,5 4,0 13,0
40,5 3,0 13,0
39,5 2,0 13,0
38,5 1,0 13,0
44,5 7,0 19,0
43,5 6,0 19,0
42,5 5,0 19,0
41,5 4,0 19,0
40,5 3,0 19,0
38,0 0,5 19,0
47,5 0,0 23,0
50,5 3,0 29,0
48,0 0,5 29,0
www.gemu-group.com
s
1,0
1,0
1,0
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
