Solar separation system
Solar XL – special variant with internal primary switching valve for 2 separate collector circuits and with internal
secondary switching valve for 2 separate tank charging circuits or pool heating system
Connection diagram:
45140.28
Collector (east)
Note:
Meibes solar controller (standard)
Priority tank =
Neutral position
Tank switching valve (currentless)
Setting direction towards tank
Primary side
576
562
70 89
1 1
3
AB
B A
2
1
1 1
183.5 65 65
Secondary side
B
A
Collector (west)
1
2
3
71
A = Valve setting A
B = Valve setting B
AB = Valve setting AB
With cover: H x W x D
850 x 600 x approx. 210 mm
MAG
Tank
Ball valve 1" internal thread
Nipple ¾"external thread
(flat sealing)
Union nut 1" internal thread
(flat sealing)
Tank
