2. Technical data
Solar separation system
Solar XL – special variant with internal secondary switching valve
for 2 separate tank charging circuits or pool heating system
Connection diagram:
45140.27
28
Collector
Primary
side
576
562
70 89
A A
B
A
A A
183.5 65 65
Secondary side
A
B
71
With cover: H x W x D
850 x 600 x approx. 210 mm
MAG
Tank 1
Ball valve 1" internal thread
Nipple ¾"external thread
(flat sealing)
Tank 2
E-7
E-9
