2. Technical data

2.2 Solar XL - special variants

Overview of the Solar XL station special variants
26
Solar XL - special variants in DN25 model,
without secondary side flow rate limiter, primary
switching valve
e.g. for two separate collector fields (east/west)
Model:
Flow rate limiter 10-40 l/min. (primary)
Primary side with Grundfos Solar PML 25-145
Secondary side with Grundfos UPM3 Hybrid 25-70
Art-No.: 45140.26
Solar XL - special variants in DN25 model,
without secondary side flow rate limiter,
with secondary switching valve
e.g. for two separate tank charging circuits or
pool heating system
Model:
Flow rate limiter 10-40 l/min. (primary)
Primary side with Grundfos Solar PML 25-145
Secondary side with Grundfos UPM3 Hybrid 25-70
Art-No.: 45140.27
Solar XL - special variants in DN25 model,
without secondary side flow rate limiter,
with primary and secondary switching valve
e.g. for two separate collector fields (east/west) and two
separate tank charging circuits
Model:
Flow rate limiter 10-40 l/min. (primary)
Primary side with Grundfos Solar PML 25-145
Secondary side with Grundfos UPM3 Hybrid 25-70
Art-No.: 45140.28
