Dip-switch for selecting functions (DS_A – DS_B)
(*) Only one (and at least one) of these Dip Switches can be in ON position.
(**) Only one (or none) of these Dip Switches can be in ON position.
5

PRESSURE BOOSTING FUNCTION

The E.box panel can be used for making a system to increase water pressure. As control inputs, either pressure switches on a pressure sensor
can be used. To operate, the panel requires an expansion vessel.
5.1

Expansion vessel

In pressure boosting it is necessary to use an expansion vessel of at least 19 litres per pump.
5.2

Electrical connections of pump and supply

Connect the supply line and the pumps as described in the chapter ELECTRICAL CONNECTIONS.
ENGLISH
N
ON
1.
o
.
STANDARD
vessels, minimum 19 litres per
1
pump.
Effective only in pressure
boosting and kiwa
Automatic exchange between
2
pump P1 and P2 every 24
hours.
Checks too frequent starts and
3
reduces them to 8 per minute
per pump.
Dry
operation
active.
Pressure
4
only. Indicates dry operation if
the pressure falls below
0.5bar.
Activates
5
mode if pressure boosting is
active.
KIWA mode switch-off delay of
6
2 seconds.
7 (**)
Pump P1 not available.
8 (**)
Pump P2 not available.
2.
N
ON status
o.
Operation
1 (*)
boosting set.
2 (*)
Operation as filling set.
3 (*)
Operation as draining set.
4
Use of electric probes.
Pressure set point scale:
5
7-16 bar / 2-5 m.
6
Not used
Regulation
7 (**)
sensor with current output.
Regulation
8 (**)
sensor with voltage output.
73
OFF
expansion
MAXI expansion vessels,
over 100 litres per pump.
Effective only in pressure
boosting and kiwa
Automatic
between pump P1 and P2
at each start.
Allows all the starts
requested by the system.
protection
boosting
Dry operation protection
not active.
KIWA
operating
Does not activate KIWA
mode.
KIWA mode switch-off
delay of 4 seconds.
Pump P1 available.
Pump P2 available.
OFF status
as
pressure
OFF
OFF
OFF
Use of floats.
Pressure set point scale:
1-10 bar / 0-3 m.
Not used
with
analog
OFF
with
analog
OFF
exchange
