Taurus Ultra Trainer TF-UT-2 Montage- Und Bedienungsanleitung Seite 38

68 Magnet sensor fixer
69 Philips self-tapping screw
70 Magnet control motor
71 Flywheel weight stack
72 Flywheel
73 Flywheel
74 Allen cylinder head half thread bolt
75 Incline motor
76 Hex self-locking nut
77 Allen cylinder head full thread bolt
78 Powder case
79 Sliding rail Axle
80 Tube cap
81 sliding rail tube cover
82 Sliding rail alumimum sheet
83 Philips C.K.S. self-tapping screw
84 Bottom cover-left
85 Bottom cover-right
86 Allen cylinder head half thread bolt
87 Allen C.K.S. hollow bolt
88 Wheels
89 Allen pan head full thread bolt
90 Tube cap
91 Hex nut
92 Feet pad
93 Rubber case
94 Motor belt
95 Top cover-middle
96 Top cover-left
97 Top cover-right
98 Water cup holder
99 Hand pulse
100 Philips pan head self-tapping screw
101 Out cover-left
102 Out cover-right
38
ST4×12
Φ450×62
M10×45×20
M10
M10×15
Φ32×Φ16×12. 7
Φ16×145.5
Φ38×17.5
ST4×20
M10×60×20
Φ8×33×M6×1 5
Φ55×25.8
M6×12
M10
Φ49×22×M10×40
110×75×3
560PJ6
ST3×30
Ultra Trainer
1
8
1
6
1
1
1
1
3
2
2
1
4
1
4
8
1
1
1
2
2
10
4
5
5
1
1
1
1
1
1
2
4
1
1
