BigRep ONE Bedienungsanleitung Seite 51

BigRep ONE
A
D
F
z
y
x
Fig. 3-2: BigRep ONE
Abb. 3-4: Filamentrollenhalter (M)
Fig. 3-3: BigRep ONE
K
Fig. 3-5: Filament spool holder (M)
B
C
A Control panel (Fig. 3-2)
B Z-guide sha s (4 pcs)
C Z-lead spindels (4 pcs)
D Filament guides (2 pcs)
E Print Bed
F Y-guide rails (2 pcs)
F
G Mobile machine base (4 pcs)
H X-guide rail
I Extruder (2 pcs)
I E H
D
M
O
P
N
D Filament guide (2 pcs)
K Adjustable roller (2 pcs)
L Adjustable bracket (2 pcs)
M Filament spool holder
N Control cabinet
L
O Main switch with door lock
P Emergency stop button
R Touchscreen
S USB port
T Reset
Construction and Function
3
incl. touch screen
G
T
S
R
Fig. 3-4: Control Panel
