Installing The 2.5 In. Hard Drive Assembly - Dell Precision 3240 Compact Servicehandbuch

Steps
1. Place the hard drive into the bracket.
2. Align and insert the pins on the drive bracket with the slots on the drive.
NOTE: Note the orientation of the hard drive so that you can replace it correctly.
Next steps
1. Install the 2.5 in. hard-drive
2. Install the front bezel.
3. Install the top cover (side
4. Install the side cover.
5. Follow the procedure in

Installing the 2.5 in. hard drive assembly

Prerequisites
Wenn Sie eine Komponente austauschen, muss die vorhandene Komponente entfernt werden, bevor Sie das Installationsverfahren
durchführen.
About this task
The following image indicates the location of the hard drive assembly and provides a visual representation of the installation procedure.
34 Ausbau und Wiedereinbau
assembly.
bezel).
after working inside your computer.
