Steps
1. Align the notch on the solid-state drive with the tab on the solid-state drive connector on the system board.
2. Insert the solid-state drive at a 45-degree angle into the solid-state drive connector.
3. Replace the screw (M2x3.5) that secures the M.2 2280 PCIe solid-state drive to the system board.
Next steps
1. Install the hard-drive assembly.
2. Install the riser card.
3. Install the fan assembly.
NOTE: This step is valid for system configuration that is shipped with 80 W CPU.
4. Install the front bezel.
5. Install the top cover (side
6. Install the side cover.
7. Follow the procedure in

WLAN-Karte

Removing the WLAN card

Prerequisites
1. Follow the procedure in
2. Remove the side cover.
3. Remove the top cover (side
4. Remove the front bezel.
5. Remove the hard-drive
About this task
The following images indicate the location of the wireless card and provide a visual representation of the removal procedure.
bezel).
after working inside your computer.
before working inside your
bezel).
assembly.
computer.
