Dell Ultra Speed-Laufwerk

Removing the Dell Ultra Speed Drive

Prerequisites
1. Follow the procedure in
2. Remove the side cover.
3. Remove the top cover (side bezel)
4. Remove the front bezel.
5. Remove the fan assembly.
NOTE: This step is valid for system configuration that is shipped with 80 W CPU.
6. Remove the riser card.
About this task
The following images indicate the location of the Dell Ultra Speed Drive and provide a visual representation of the removal procedure.
50 Ausbau und Wiedereinbau
before working inside your computer.
