Table 7. Screw list (continued)
Component
System board
Riser card

Seitenabdeckung

Removing the top cover (side bezel)

Prerequisites
1. Follow the procedure in
NOTE: Turn the optional SMA antenna downwards or remove it for convenient sliding of the top cover (side bezel).
About this task
The following image indicates the location of the top cover (side bezel) and provides a visual representation of the removal procedure.
before working inside your
Screw type
M3x4
#6-32
M3x5
computer.
Quantity Image
3
4
2
Ausbau und Wiedereinbau 21
