2.6 CHARGING BASE

E1. Power indicator
E2. Power adapter
E3. Charging pin
E4. Power adapter charging port
VIRTUAL WALL
V1 Power on/ off
V2 Signal emitter
V3 Indicator
V4 Battery lid

2.7 REMOTE CONTROL

F1 Back to charging base
F2 Direction button
F3 Auto mode / Pause active mode
F4 Suction power / water flow in mopping mode
F5 Effective mode
F6 Spot mode
F7 Edge mode
Spare parts for replacement:
ETA151500160 - Main brush
ETA151500170 - Unique rubber brush
ETA151500240 - Remote Control
ETA151500070 - Side brush (2 pcs)
ETA151500260 - Clean tool
ETA151500090 - HEPA filtr + Foam filter
ETA151500220 - Primary filter
ETA151500110 - Dust bin
ETA151500210 - Charging base
ETA151500250 - Power adapter
ETA151500120 - Mop adapter with water tank
ETA151500150 - Cover of main brush
ETA151500190 - Battery
ETA151500280 - Virtual wall
E1
E2
E3
E4
V1
V2
V4
F1
F2
F3
F4
F5
F6
F7
EN - 63
EN
V3
