Gemü 567 BioStar control Betriebsanleitung Seite 68

7 Dimensions
7.2.13 Clamp with bypass code 86
LE
DN
Seat L
size
(code)
8 A
53
B
53
C
53
10 A
53
B
53
C
53
D
53
15 A
53
B
53
C
53
D
53
E
53
G
53
Dimensions in mm
1) Connection type
Code 86: Clamp DIN 32676 series A
2) Valve body material
Code 41: 1.4435 (316L), block material
Code 43: 1.4435 (BN2), block material, Δ Fe < 0.5%
GEMÜ 567
L
H1
d1
d3
Connection type code 86
Material code 41, 43
□ E Ø z LE1
75 2 68.5
75 4 68.5
75 6 68.5
75 2 67.5
75 4 67.5
75 6 67.5
75 8 67.5
75 2 64.5
75 4 64.5
75 6 64.5
75 8 64.5
75 10 64.5
75 15 64.5
1)
2)
LE2 H1
73.5 17.5
72.5 17.5
71.5 17.5
74.5 18.5
73.5 18.5
72.5 18.5
71.5 18.5
77.5 21.5
76.5 21.5
75.5 21.5
74.5 21.5
73.5 21.5
71.0 21.5
68 / 88
H2 cz Ø d1
40.5 3.0 8
39.5 2.0 8
38.5 1.0 8
41.5 4.0 10
40.5 3.0 10
39.5 2.0 10
38.5 1.0 10
44.5 7.0 16
43.5 6.0 16
42.5 5.0 16
41.5 4.0 16
40.5 3.0 16
38.0 0.5 16
www.gemu-group.com
Ø d3
25
25
25
34
34
34
34
34
34
34
34
34
34
